SPESIFIKASI
| Model | Ice making capacity | Rated power | Circulating water pump power | Cooling water pump power | Cooling fan power | Machine dimention | Weight of machine |
| No | Ton/24h | KW | KW | KW | KW | LXWXH(mm) | KG |
| MB10 | 1.0 | 3.92 | 2.2 | 1.5 | 0.37 | 2820*1410*965 | 900 |
| MB20 | 2.0 | 7.11 | 2.2 | 1.5 | 0.55 | 1700*750*1500
2220*1440*1065 |
1100 |
| MB30 | 3.0 | 9.68 | 2.2 | 2.2 | 0.75 | 1800*750*1500
3000*1380*1065 |
1300 |
| MB40 | 4.0 | 12.56 | 4 | 2.2 | 0.75 | 2000*800*1600
3110*1470*1075 |
1500 |
| MB50 | 5.0 | 14.6 | 4 | 2.2 | 1.5 | 200*800*1600
4560*1380*1150 |
1700 |
| MB60 | 6.0 | 18.84 | 4 | 2.2 | 1.5 | 200*800*1600
5340*1380*1150 |
1900 |
| MB80 | 8.0 | 21.30 | 4 | 4 | 1.5 | 2000*1000*1800
7720*1950*1150 |
2300 |
| MB100 | 10.0 | 26.60 | 5.5 | 4 | 1.5 | 2500*1200*2000
6360*3710*1565 |
2700 |
| MB150 | 15.0 | 48.30 | 7.5 | 5.5 | 2.2 | 3100*1200*2000
9280*2260*1560 |
3700 |
| MB200 | 20.0 | 63.0 | 7.5 | 7.5 | 3.75 | 3500*1500*2200
11560*4200*1565 |
4700 |
| MB250 | 25.0 | 68.7 | 7.5 | 7.5 | 3.75 | 3500*1500*2200
12080*2260*1560 |
5700 |
| MB300 | 30.0 | 76.4 | 7.5 | 15 | 5.5 | 3500*1500*2200
11560*7080*1600 |
6700 |
| MB400 | 40.0 | 126 | 15 | 15 | 7.5 | 2*3500*1300*2200
11560*7080*1600 |
8700 |
| MB500 | 50.0 | 137.4 | 15 | 15 | 7.5 | 2*3500*1300*2200
14170*7080*1600 |
10700 |
| MB1000 | 100.0 | 274 | 30 | 30 | 15 | 4*3500*1300*2200
12000*13500*1450 |
21400 |
==================================================================================================================================================
==================================================================================================================================================
==================================================================================================================================================
Product Features:
The temperature of ice low and it can reach 10 celcius below zero.
Because of the block structure , it is conventent for store.
The Integrity design and installation convenience , it can be used if yoyu install electricity and water.
The principle is s imple and maintenance and repair is easy.
The ice-making Tank adopt the Polyurethane foam technology. It promises a good heat insulation.
It can be made defferent size ice block machine to meet different currents need to ice.
The large ice block machine use the lane to take ice, so the work quantity is small.
There are 1 ton to 100tons production per day models to choose.
